Find your Simple Pay solution
As a customer of Simple Pay, you will have different solutions to choose from. Together we will find the best solution.
What we offer
With our solution, you get an easy payment system without the need for administration or contact to the users.
Our terminals can control up to 8 machines and are easily operated by the user through our website.
Changing the duration or cost of a machine can be done remotely, to simplify the procces.
The solution
Your solution works by controlling a signal. This signal can open a switch relay, timer relay, contact, etc. This modularity makes it easy to integrate into existing systems. For example:
- 1- or 3-phase applications
- Low- or high-current applications
- Momentarily activation applications
The terminal is a one-time purchase and does not have any subscriptions. It is controlled through our website, where every service to be activated is brought. We take a 10% cut of the purchases on our website - with a minimum amount of 20 dkk each month per terminal. As a consumer, you will not have to handle transactions from the users. And at the end of the month, we will transfer the profit of your terminal(s) to you.
Our newest product
The terminal is capable of controlling 8 outputs, with the control voltage ranging from 3.3V to 48V.
The box containing the product is ABB AP9 which is IP65. The dimensions of the box (W: 86 mm, H: 39 mm, L: 86 mm). Using this box makes the installation process easy, due to the design of the box. It is also durable since it is dust-tight and withstands water, and can be mounted outdoor.
The board can operate on WiFi, or through the Ethernet connector (red).
Power options of the board are either through the USB-C connector or the push connectors for ≤ 0.75 mm² cables (yellow), with the voltage of 3.3V to 5V.
The 8 output channels (blue) are push connectors for ≤ 0.75 mm² cables. The control voltage is identical to the power push connector.
Contact us
If you are interested or want to hear more about our solutions, you are always welcome to contact us: sale@simplepay.dk
